CODE – 01-132-980
NAME – P9S Suppressed
COUNTRY OF ORIGIN – Germany
DATE OF MANUFACTURE – 1980
CALIBER – 9x19mm
OVERALL LENGTH – 20.8 cm (8.19 in) without suppressor
OVERALL LENGTH – 39.1 cm (15.38 in) with suppressor
SUPPRESSOR LENGTH – 19.7 cm (7.75 in)
SUPPRESSOR DIAMETER – 3.5 cm (1.382 in)
BARREL LENGTH – 11.7 cm (4.63 in)
RIFLING (TYPE & TWIST) – Polygonal, 4 Groove, Right-hand twist, 1 turn in 25 cm (9.84 in)
BULLET DIAMETER – 9.02mm (0.355 in)
BULLET WEIGHT – 10.24 g (158 grains)
MUZZLE VELOCITY – 294 m/s (965 fps)
MUZZLE ENERGY – 443 j (327 ft/lb)
WEIGHT (EMPTY) – 0.88 kg (1 lb 15 oz)
SUPPRESSOR WEIGHT – 0.59 kg (1 lb 5 oz)
WEIGHT (LOADED) – 1.675 kg (3 lb 11 oz) loaded with 9 rounds Mk 144 Mod 0 subsonic ball, with suppressor
SIGHTS – Open, iron, adjustable for zero, Front sight – Square blade on dovetail base, Rear sight – Square notch on dovetail base
EFFECTIVE RANGE – 30 m (33 yards)
OPERATION – Recoil, Delayed roller locked bolt system
TYPE OF FIRE – Semiautomatic, Double-action
RATE OF FIRE – 27 rpm
FEED DEVICE – 9 round box magazine, single column, single feed
FEED DEVICE WEIGHT (EMPTY) – 0.075 kg
FEED DEVICE WEIGHT (LOADED) – 0.205 kg
BASIC AMMUNITION LOAD – Two – 9 round magazines (18 rounds)
LOAD WEIGHT – 0.41 kg (14.5 oz)
MANUFACTURER – Heckler & Koch GmbH, Oberndorf/Neckar, Germany, Qual-A-Tech Suppressors
STATUS – Obsolescent
SERVICE – US Navy Special Operations (SEALs)
