03A-041-985

NAME – HK 94 SG/1

NAME (NATIVE) – HK 94 Scharftschutzen Gewehr 1

COUNTRY OF ORIGIN – Germany

DATE OF MANUFACTURE – 1985

CALIBER – 9x19mm

OVERALL LENGTH – 93.3 cm (36.75 in)

BARREL LENGTH – 42 cm (16.54 in)

RIFLING (TYPE & TWIST) – 4 Grooves, Right-hand twist, 1 turn in 25 cm (1 turn in 9.86 in)

LOAD – Full metal jacketed ball

BULLET DIAMETER – 9.02mm (0.355 in)

BULLET WEIGHT – 8.04 g (124 grain)

MUZZLE VELOCITY – 430 m/s (1410 fps)

MUZZLE ENERGY – 742 j (547 ft/lb)

WEIGHT (EMPTY) – 3.26 kg (7 lb 3 oz) without telescopic sight or bipod

WEIGHT (LOADED) – 4.38 kg (9 lb 11 oz) with telescopic sight and mount, loaded with 15 rounds Ball

WEIGHT (MOUNTED) – 4.69 kg (10 lb 5 oz) with bipod, telescopic sight and mount, loaded with 15 rounds Ball

TYPE OF MOUNT – Folding bipod

WEIGHT OF MOUNT – 0.31 kg (11 oz)

SIGHTS – Open iron, adjustable, Front – Ring-protected fixed blade, Rear – Rotating vertical drum with 4 peep apertures of varying size, Adjustable for windage and elevation, Factory zeroed to 25 m (27 yards)

OPTICAL SIGHT – Leupold M8-6x Compact

OPTICAL SIGHT WEIGHT – 0.82 kg (1 lb 13 oz) with mount

OPTICAL SIGHT MAGNIFICATION – 6 Power

OPTICAL SIGHT FIELD OF VIEW – 3.2 degrees – 5.6 m @ 100 m (17 ft @100 yds)

OPTICAL SIGHT ADJUSTMENTS – Plus or minus 0.9 m at 100 m (32 in at 100 yards)

EFFECTIVE RANGE – 200 m (219 yards)

OPERATION – Roller-delayed blowback, fires from closed bolt, hammer fired

TYPE OF FIRE – Semiautomatic

RATE OF FIRE – 10 to 30 rpm

FEED DEVICE – 15 or 30-round curved box magazine, Double column, Double feed

FEED DEVICE WEIGHT (EMPTY) – 15-round – 0.12 kg (4.23 oz), 30-round – 0.17 kg (6 oz)

FEED DEVICE WEIGHT (LOADED) – 15-round – 0.30 kg (10.6 oz), 30-round – 0.53 kg (1 lb 2.7 oz)

BASIC AMMUNITION LOAD – Two-15 round magazines (30 rounds)

LOAD WEIGHT – 0.60 kg (1 lb 5 oz)

MANUFACTURER – Heckler & Koch GmbH, Oberndorf/Neckar, Germany

STATUS – Production completed

SERVICE – Commercial sales
